Siglent SDS2104 4-kanaals scope
Details
Binnenkort beschikbaar!
Voor meer informatie, zie het productblad.
-Inovative SPO technology
-Long Memory Depth up to 28Mpts
-Waveform capture rate up to 110.000 wfs/s
-Advanced Math operations (FFT, integral, differential, square root )
-Buildin waveform generator with a max frequentie of 25MH
-Analog channel bandwidth 70MHz, 100MHz, 200MHz, 300MHz
-Real-time sampling rate of the analog channels 2GSa / s, digital channel 500MSa / s (MSO function)
-2/4 analog channels, 8 digital channels (MSO function)
-Built-in 25MHz function arbitrary waveform generator (optional)
-support rich serial bus triggering and decoding functions (IIC, SPI, UART / RS232, CAN, LIN)
-Support Smart Trigger (Window, Runt, Interval, DropOut, Pattern) and high-definition HDTV video triggering
-Zoom done by hardware implementation and high-speed Pass / Fail function
-32 kinds of automatic measurement functions, statistical functions to support measurement
-Advanced Math functions (FFT, integral, differential, square root)
-Interface: USB Host, USB Device (USBTMC, PictBridge), LAN (VXI-11, LXI-C), EXT TRIG, PASS / FAIL, TRIG OUT
-support rich SCPI remote control commands
-Multi-language display and embedded online help system
- 8 " TFT (800 * 480) LCD screen
MSO/SDS2000 Series Superphosphor oscilloscopes maximum bandwidth of 300MHz, sample rates up to 2GSa / s, both deep memory, high refresh, multi-level gray scale and other characteristics, is a technologically advanced, high-performance general-purpose digital instruments. Its unique SPO technology, making it the industry leader in digital oscilloscope, digital oscilloscope for the domestic sphere has opened up a new era.
